Type 1 AC surge protector 4 poles 25kA JLSP-BC25/4P

Type 1+2 AC power surge protector, type 1 surge protector, 3 phase surge protector

Iimp:25kA

In: 50kA

Low voltage Up

Internal disconnection, statue indicator, and remote signaling

IEC 61643-11

OEM/ ODM

Item NO.:
JLSP-BC25/4P

Inquire now

Product Detail

Type 1+2 AC power surge protection device three phase SPD 25kA

3 phase surge protector, type 1 2 surge arrester, t1 t2 ac spd, OEM surge protection device supplier

ODM surge protection device manufacturer

AC power surge protective device is used in AC power supply system (50/60Hz) and low-voltage control system to protect from lightning striker and transient over-voltage. The maximum operating voltage (Uc): 175V, 275V, 350V, 385V, 440V, 485V and 750V.

Standard compliance: IEC61643-11, EN61643-11

IEC 61643-11 Surge protective devices connected to low-voltage power distribution systems -Part 11: Performance requirements and testing methods

Features:

* Reliable thermal tripping protection

* Status indicator: Transparent(normal) Red（Defect）

* Fast response: action within nanosecond

* Optional remote signaling

* Easy to mount

* Latest reflow soldering process, ensure product consistency

Model	JLSP-BC25/4P
Descrpition	Type 1+2 AC surge protector-4poles
Network	230/400V (TN/TT/IT)
Max. AC operating voltage (Uc)	385V
Lightning impluse current Iimp(kA)	25kA
Nominal discharge current In(kA)	50kA
Protection level Up (kV)	≦2.0kV
Dimensions	1449065MM
Protection rating	IP 20
Response time tA (ns)	≦25
Oeprating temperature	-40/+85℃
Mounting	DIN Rail 35mm
Housing material	Thermoplastic UL94-V0
Standards compliance	IEC64643-11, GB/T18802.11

type 1 2 surge protection device

Keywords: type 1 surge protector, type 1 surge protection device, type 1 surge protection, ac spd, ac surge protection device, 3 phase surge protector, 3 phase surge protector device, type 1 2 spd
